The Nicks Gate Aluminium Angle Picket Gate | Edgesmith

Nicks Gate

Name: Nicks Gate
Brand: Edgesmith
Availability: InStock

Brand:

Edgesmith

Product Type:

Aluminium Angle Picket Gate

A modern architectural styled panel with striking vertical angle picket closely spaced to accentuate the vertical lines of the house.

Type:

Swing Slide Cantilever Pedestrian

Movement:

Automated Manual

Variant

Contact for Pricing

More information

Extended Description

A modern architectural styled panel with striking vertical angle picket closely spaced to accentuate the vertical lines of the house. Fence panels, balustrade panels and a matching series of gates compliment the range.

Nicks Panels are all custom-made in our Silverdale factory and can be supplied with matching posts. Pedestrian gates and driveway gates will be made to the size of your driveway in our fabrication department. It can be supplied with suitable gate motors for a qualified technician to install. Typical lead times are 2-3 weeks.

Features + Applications

Features

Lasts longer than timber
No warping or fading
Smooth finish and clean minimalist look

Applications

Landscape Fencing
Infill panels on block walls
Balustrade compliant (when there is a drop of over 1m, panels are required to be balustrade compliant and be supplied with a producer statement to confirm it).
Pool fencing compliant at 1.2m high.
Slide, Swing and Cantilever Gates and custom panels are also available made and priced to order.

Gate Specifications

Gates are made to order in our Silverdale factory. The table below shows our standard sizes. Larger sizes require an engineered solution and may require extra strengthening in the frame, special hinges or wheels etc. Please call us to work through your requirements.

Type	Opening Width	Frame Details
Pedestrian	1.2m opening	Aluminium 40x40mm frame with 65x16mm rectangular pickets at 65mm spacings
Swing	Up to 4m single swing, 8m double	Aluminium 50x50mm frame with 65x16mm rectangular pickets at 65mm spacings
Sliding	Up to 6m	Aluminium 75x100mm bottom rail and 75x75mm sides and top with 65x16mm rectangular pickets at 65mm spacings
Cantilever	Up to 5m	Aluminium 50x100mm bottom rail and 50x50mm sides and top with 65x16mm rectangular pickets at 65mm spacings

Documents

Product brochures, technical standards and producer statements give you peace of mind when specifying Edgesmith Products.

Download Product Guide

Nicks Gate

POA
