Mercury School Panel

Name: Mercury School Panel
Brand: Edgesmith
Availability: InStock

POA

Brand:

Edgesmith

SKU:

Product Type:

Aluminium Raking Panel

The Mercury Panel ticks all the boxes. It’s a low-cost aluminium raking panel that is easy to install and won’t ever rust.

Height:

1.5m Flat Top 1.6m Flat top 1.8m Flat Top

Finish:

Black Powder Coat Custom Powder Coat

Brackets:

U-Brackets (0-30deg) Raking Tube Brackets (0-15deg)

Variant

More information

Description

The Mercury School Panel ticks all the boxes. It’s a cost effective aluminium raking panel that is easy to install and won’t ever rust. Four configurations: Pool, Balustrade, School and Security, all based around a patented raking mechanism that allows the panel to rake up to 30 degrees making this the ultimate versatile fence and balustrade panel

Chunky 25mm SHS pickets are rigidly fixed to the rails with an innovative and patented mechanism that doesn’t need a large gap in the rail and is super rigid when fixed into the posts. Gates are available for pedestrians or driveways, made to order to fit your opening. Typical lead times are 1-2 weeks.

Features + Applications

Features:

Rakes up to 30 deg with U-Brackets, 15 deg with Tube Brackets
Pool Fence Compliant across full range (except 1m high panel)
Balustrade Compliant (U-Brackets only)

Applications:

Balustrade Fencing - Compliant to NZS3604 at full width. Commercial panel with 50x40 top rail and 65SHS steel posts for parks, schools, apartments and commercial applications. Residential panel with 40x40 rails and 65SHS aluminium posts for single dwelling residential applications.
Pool Fencing Pool compliant to NZS8500.
School Fencing - 1.5 and 1.8m high flat top raking aluminium fence panel (3 Rails) and also 1.6m high flat top raking panel (2 Rails). Panels are 2.325m wide with 25mm SHS pickets. Meets the specifications of Education New Zealand - School Fencing Design Guideline with 65 SHS posts.
Security Fencing - 1.8 and 2.1m high spike top raking aluminium fence panel. 2.325m wide 3 rail panels with 25mm SHS pressed spear pickets. Ideal for security fencing across undulating terrain.

Downloadable Documents

Product brochures, technical standards and producer statements give you peace of mind when specifying Edgesmith Products.

Mercury School Panel

POA
