Slide Gate Code Lock

Premium mechanical code lock for sliding gates with aluminium housing and stainless steel mechanism. Because no electricity or batteries are required, this system gives you the opportunity to equip any sliding gate fast and easily with access control. The unique Twistfinger and according self-correcting keep guarantees a perfect aligned closing of your sliding gate. For a fast and highly precise installation, we recommend using the Drill-Fix drilling caliber.

Specifications:

• Gate Gap = 30 - 35mm
• 100% mechanical: no battery nor electricity required
• Adjustable for horizontal or vertical mounting of the keep (catch bolt)
• Mechanical code panel on both sides
• Possibility to work with different entrance and exit codes
• Equipped with dust and rain covers
• Easy and fast set-up or modification of the access codes
• Possibility of setting up 4 to 6 digit codes
• Extremely strong and user-friendly mechanism
• Automatic code reset after pushing the handle
• Anti-code detection with integrated security press plate
• Stainless steel collar around the Twistfinger prevents cutting through the twistfinger (catchbolt)

Edgesmith's technical support provides you with the support you need to have confidence when specifying or installing.

• Download Installation Guide
